| 產品介紹 > 存儲系統
> 超高速儲存零配件> LSI 6Gb/s SATA+SAS RAID Controller Cards |
 |
| LSI 6Gb/s SATA+SAS RAID Controller Cards |
| Designed to deliver breakthrough IOPS and bandwidth performance for high-performance computing, medical imaging, digital content development, and other highly demanding applications, these controller cards offer 6Gb/s or legacy 3Gb/s transfer rates; PCIe 2.0 host connectivity; support for SATA, SAS or solid-state devices; and LSI advanced software options for select MegaRAID controllers. |
| |
|
|
MegaRAID SAS 9280-24i4e
24 Ports internal, 4 ports external, PCIe 2.0
- 24 internal + 4 external 6Gb/s SATA+SAS ports
- 6 internal mini-SAS SFF-8087 x4 connectors
- One mini-SAS SFF-8088 external connector
- Half-Length, Full Height (6.6” x 4.376”)
- 512MB DDRII cache (800MHz) |
| |
|
| |
|
|
MegaRAID SAS 9280-16i4e
16 Ports internal, 4 ports external, PCIe 2.0
- 16 internal + 4 external 6Gb/s SATA+SAS ports
- 4 internal mini-SAS SFF-8087 x4 connectors
- One mini-SAS SFF-8088 external connector
- Half-Length, Full Height (6.6” x 4.376”)
- 512MB DDRII cache (800MHz) |
| |
|
| |
|
 |
MegaRAID SAS 9280-8e
8 Ports external, low-profile PCIe 2.0
- 8 external SATA+SAS ports
- Two mini-SAS SFF-8088 x4 connectors
- Low-profile MD2 form factor (6.6” X 2.536”)
- 512MB DDRII cache (800MHz) |
| |
|
| |
|
 |
MegaRAID SAS 9280-4i4e
4 Ports internal, 4 ports external, low-profile PCIe 2.0
- 4 internal + 4 external 6Gb/s SATA+SAS ports
- One mini-SAS SFF-8087 x4 internal connector
- One mini-SAS SFF-8088 external connector
- Low-profile MD2 form factor (6.6” X 2.536”)
- 512MB DDRII cache (800MHz) |
| |
|
| |
|
| Providing a carefully designed balance between data protection features, performance, and cost, these controller cards are designed to deliver data quickly and reliably to mission-critical applications for small-and-medium size businesses, as well as a wide variety of cloud, security, and core business applications. |
| |
|
 |
MegaRAID SAS 9260-16i
16 Ports internal, PCIe 2.0
- 16 internal SATA+SAS ports
- Four mini-SAS SFF-8087 x4 connectors
- Half-Length, Full Height (6.6” x 4.376”)
- 512MB DDRII cache (800MHz) |
| |
|
| |
|
 |
MegaRAID SAS 9260-8i
8 Ports internal, low-profile PCIe 2.0
- 8 internal SATA+SAS ports
- Two mini-SAS SFF-8087 x4 connectors
- Low-profile MD2 form factor (6.6” X 2.536”)
- 512MB DDR II cache (800MHz) |
| |
|
| |
|
 |
MegaRAID SAS 9260-4i
4 Ports internal, low-profile PCIe 2.0
- 4 internal SATA+SAS ports
- One mini-SAS SFF-8087 x4 connector
- Low-profile MD2 form factor (6.6” X 2.536”)
- 512MB DDRII cache (800MHz) |
| |
|
|
|
|
