| Nytro MegaRAID Application Acceleration Card |
| |
|
|
The Nytro MegaRAID® card combines on-board flash technology with LSI market segment leading RAID-on-Chip (ROC) technology to help accelerate key business applications, using intelligent caching algorithms to help identify application “hot spots” and promote them to fast on-board NAND flash. |
The Nytro MegaRAID card is designed to deliver intelligent application acceleration and enterprise level data protection while offering cost savings over solid state drive (SSD)-only arrays or over-provisioned direct attached hard disk drive (HDD) environments.
• Dual core, enterprise-grade RAID-on-chip and on-card flash storage for optimum
performance and data protection
• Sophisticated caching algorithms migrate frequently accessed data to flash storage
• Hot spot data on flash also means faster HDD array rebuild times
• Low profile, MD2 form factor, PCIe 3.0 compliant, with support for 6Gb/s SAS or
SATA devices.
Name |
Memory Type |
Capacity |
Part Number |
| Nytro MegaRAID 8100-4i |
SLC |
100GB |
LSI00350 |
| Nytro MegaRAID 8110-4i |
eMLC |
200GB |
LSI00351 |
| Nytro MegaRAID 8120-4i |
eMLC |
800GB |
LSI00353 |
| Nytro MegaRAID SCM-01 SuperCap kit for DRAM Cache Protection |
LSI00355 |
 LSI® Nytro™ MegaRAIDR
Application Acceleration Card
LSI® Nytro™ MegaRAID Application Acceleration Card for DAS
Improving Database Performance by Using the LSI® Nytro™ MegaRAID® Application Acceleration Card for DAS
|
| Nytro XD Application Acceleration Storage Solution |
| |
|
|
Nytro XD BLP4-400 Application Acceleration Storage Solution
A solution designed to dramatically improve application performance in SAN and DAS storage environments by intelligently caching the most frequently accessed data on flash storage. The LSI Nytro XD solution includes host-based software designed to detect hot spots of frequently accessed data and store them in a LSI Nytro WarpDrive application acceleration card. |
|
| |
• Hot spots areautomatically detected and placed in LSI PCIe flash storage
• Accelerated all logical volumes in a SAN or directly attached (DAS)
• Analyses access patterns as they change
• Migrates new "hot" data to LSI PCIe flash storage over time |
| |
Name |
Memory Type |
Capacity |
Part Number |
Card Size |
| XD BLP4-400 |
eMLC |
400GB |
LSI00325 |
MD2 Low Profile |
|
| |
| LSI® Nytro™ XD Application Acceleration
Storage Solution |
| |
| Nytro WarpDrive Application Acceleration Card |
| |
|
|
The new family of LSI Nytro WarpDrive application acceleration cards is designed to offer high performance with low latency and a low CPU burden for efficient application acceleration. |
|
| Their PCIe® host interface, industry standard drivers and small form factor make them more flexible and easier to integrate into today's low profile, high performance system chassis. |
| |
• High performance PCIe® solid state storage
• Low latency and a low CPU burden
• Designed to maximize transactional I/O
performance
- Online transaction processing
- Web serving
- Data analytics and warehousing
- Data mart and Data mining
- High-Performance computing |
| |
Name |
Memory Type |
Capacity |
Part Number |
Card Size |
| WLP4-200 |
SLC |
200GB |
LSI00323 |
MD2 Low Profile |
| WLP4-400 |
SLC |
400GB |
LSI00324 |
MD2 Low Profile |
| BLP4-400 |
eMLC |
400GB |
LSI00318 |
MD2 Low Profile |
| BLP4-800 |
eMLC |
800GB |
LSI00319 |
MD2 Low Profile |
| BLP4-1600 |
eMLC |
1.6TB |
LSI00320 |
MD2 Low Profile |
|
| |
| LSI® Nytro™ WarpDrive™ Application Acceleration Card |
| |
| |
