| XILINX ALVEO FPGA Accelerator Cards |
Adaptable Accelerator Cards for
Data Center Workloads
|
| |
 |
ALVEO U25
This SmartNIC delivers ultra-high throughput, small packet performance and low-latency for modern data centers.
|
For cloud architects building modern data centers, the Alveo U25 provides a comprehensive SmartNIC Platform that brings true convergence of network, storage, and compute acceleration functions onto a single platform.
The U25 SmartNIC Platform is based on a powerful FPGA, enabling hardware acceleration and offload to happen inline with maximum efficiency while avoiding unnecessary data movements and CPU processing. The U25 programming model supports both high-level network programming abstractions such as HLS and P4, as well compute acceleration frameworks such as Vitis™ to enable both Xilinx and 3rd party accelerated applications.
Compute Resources
|
Look-up Tables (LUTs) :
522K |
| Dimensions |
Height : 2.54 inch (64.4 mm)
Length : 6.60 inch (167.65 mm)
Width : Single x16 PCIe Slot |
On-board Memory
|
DDR :
- 1x 2GB x 40 DDR4-2400
- 1x 4GB x 72 DDR4-2400 |
| Interfaces |
PCI Express :
Gen3 x16, bifurcated to 2x Gen3 x8 depending on use case
Network Interfaces : 2x SFP28 |
| Time Stamp |
Hardware Time Stamping : Yes (1588) |
| Networking |
Stateless Offloads : Yes
Tunneling Offloads : VXLAN / Geneve
SR-IOV : Yes
Advanced Packet Filtering : Yes
Acceleration : DPDK, Onload® |
| Manageability Support |
NC-SI over MCTP SMBus : Yes
PLDM over MCTP SMBus / MCTP PCIe VDM : Yes
PXE and UEFI boot support : Yes |
| Power and Thermal |
Maximum Total Power : 75W
Thermal Cooling : Passive |
| Tool Support |
Vitis Developer Environment : Yes
Vivado Design Suite : Yes |
 ALVEO U25 型錄下載
 |
ALVEO U50
Delivers compute, networking, and storage acceleration in an efficient 75-watt, small form factor, and armed with 100 GbE networking, PCIe Gen4, and HBM2. Designed to deploy in any server.
|
The Xilinx® Alveo™ U50 Data Center accelerator cards provide
optimized acceleration for workloads in financial computing,
machine learning, computational storage, and data search and
analytics. Built on Xilinx UltraScale+™ architecture and packaged in
an efficient 75-watt, low-profile form factor, the U50 includes 8GB
HBM2, 100GbE networking, and PCI Express 4.0 and is designed
for deployment in any server.
Compute Resources
|
Look-up Tables (LUTs) : 872K
Registers : 1,743K
DSP Slices : 5,952 |
| Dimensions |
Height : 1/2 Height
Length : 1/2 Length
Width : Single Slot |
Memory
|
HBM Memory Capacity : 8 GB
HBM Total Bandwidth : 316 GB/s *
Internal SRAM Capacity : 28 MB
Internal SRAM Total Bandwidth : 24 TB/s |
| Interfaces |
PCI Express :
Gen3x 16, 2 x Gen4x 8, CCIX
Network Interfaces : 1x QSFP28 (100GbE) |
| Time Stamp |
Clock Precision : IEEE 1588 |
| Power and Thermal |
Maximum Total Power : 75W
Thermal Cooling : Passive |
| Tool Support |
Vitis Developer Environment : Yes
Vivado Design Suite : Yes |
ALVEO U50 型錄下載
 |
ALVEO U200 / U250
U200 -- Incredible compute, networking, and storage acceleration thanks to 890k LUTs, 5.9k DSP slices, 64GB of DDR4 memory, and dual 100Gbps network interfaces.
U250 -- Offers 1.3M LUTs, 11.5k DSP slices, 64GB of DDR4 memory, dual 100Gbps network interfaces, and delivers 90x higher performance than CPUs on key workloads at a fraction of the costs. |
Xilinx® Alveo™ Data Center accelerator cards are designed to
meet the constantly changing needs of the modern Data Center,
providing up to 90X performance increase over CPUs for common
workloads, including machine learning inference, video transcoding,
and database search and analytics.
With complex algorithms evolving faster than silicon design cycles,
it’s impossible for fixed function GPU and ASIC devices to keep
pace. Built on Xilinx 16nm UltraScale™ architecture, Alveo U200 and
U250 accelerator cards provide reconfigurable acceleration that
can adapt to continual algorithm optimizations, supporting any
workload type while reducing overall cost of ownership.
Compute
|
INT8 TOPs (peak) : 18.6 (U200) / 33.3 (U250) |
| Dimensions |
Height : Full
Length : 3/4 (Passive) / Full (Active)
Width : Dual Slot |
Memory
|
Off-chip Memory Capacity : 64GB
Off-chip Total Bandwidth : 77GB/s
Internal SRAM Capacity : 35MB (U200) / 54MB (U250)
Internal SRAM Total Bandwidth :31TB/s(U200) / 38TB/s(U250) |
| Interfaces |
PCI Express : Gen3 x16
Network Interfaces : 2x QSFP28(100GbE) |
| Logic Resources |
Look-up Tables (LUTs) : 892,000 (U200) / 1,341,000 (U250) |
| Power and Thermal |
Maximum Total Power : 225W
Thermal Cooling : Passive or Active |
ALVEO U200 / U250 型錄下載
 |
ALVEO X3 Series
- X3522 Low Latency Network Adapter
- X3522PV Accelerator Card
Today’s leading trading firms, market makers, hedge funds, and exchanges
demand low latency trade execution and risk management for competitive
advantage. |
Available in two variants, the Alveo X3522 low latency network adapter provides a low latency NIC with an optional upgrade for user programmability.
The Alveo X3522PV adaptable accelerator card provides a fully programmable option for fintech customers to implement a customized, low latency solution.
Collectively, the portfolio reduces overall system latency by bringing compute closer to the wire.
| Board Specifications |
X3522
Low Latency Network Adapter
X3522PV
Adaptable Accelerator Card |
| Network Configuration |
4x10/25GbE* ports |
| Form Factor |
Half Height, Half Length PCIe® Single slot |
| Connectivity |
2x DSFP Cages
Direct Attach Copper (DAC), or SR Optics
1 PPS In/Out SSMB Connectors |
| Host Interface |
PCIe Gen3 x8 / Gen4 x8 |
| FPGA Device |
16nm UltraScale+™ XCU35 FPGA (-3 Speed Grade) |
| Logic Density |
X3522 Low Latency Network Adapter :
400K LUTs
(via Software Upgrade Option)
X3522PV Adaptable Accelerator Card:
1M LUTs |
| SW Programmability |
X3522 Low Latency Network Adapter :
Vitis™ HLS Software Environment
X3522PV Adaptable Accelerator Card:
Vivado® Design Suite |
| Network Acceleration |
X3522 Low Latency Network Adapter :
. Onload®- BSD sockets compliant TCP/UDP kernel bypass
. TCPDirect- TCP/UDP kernel bypass
. ef_vi API for high performance raw Ethernet networking
. Low latency optimized cut-through architecture
X3522PV Adaptable Accelerator Card:
N/A |
| Ordering Information |
X3522 Low Latency Network Adapter :
A-X3522-P08G-PQ-G
4-port, 10/25GbE PCIe low latency network adapter
SW-X3522-001
. X3522 configuration file to enable programmability
. SKU provides a license to use the config file to upgrade a single X3522 adapter to enable programmability
X3522PV Adaptable Accelerator Card:
A-X3522PV-P08G-PQ-G
4-port,10/25GbE adaptable accelerator card |
ALVEO X3 Series 型錄下載
|
|
|
|
