 ARAVision Wolf & Wolf Plus 1U CPU Overclocked HFT Server

已取得
中華民國(臺灣)專利 Patents of R.O.C. (Taiwan)
專利號碼 (Patent No.) :
發明第 I777641 號、 新型第 M618657 號、 新型第 M620968

中華人民共和國新型專利 Patents of P.R.O.C (China)
專利號碼 (Patent No.) : ZL 2022 2 0562480.0ZL 2022 2 0538828.2

德國新型專利 Patents of Germany
專利號碼 (Patent No.) : 20 2022 103 53120 2023 101 484

日本新型專利 Patents of Japan
專利號碼 (Patent No.) : 32420013242002


When the market reaches the touch stage


Wolf can make your strategy logic execute the order at the fastest speed, allowing you to surpass other competitors and quickly obtain transaction returns. For light usage or budget considerations, it is enough to choose Wolf Warrior as an excellent weapon in the financial battlefield. If your transaction is heavy usage, or you want to obtain stronger and stable performance, we sincerely recommend you to choose Wolf Warrior Plus.

Key Features :
* Can effectively improve your strategy trigger
* Design with air-flow cooling and liquid-cooled models for choice
* Provide 10 CPU cores, all cores frequency are optimized for 4.9GHz
* Excellent liquid-cooled and thermal flow only in 1U form
* Most 4 x high-speed I/O slots for different AP designed architectures
* Up to 45%~60% performance than traditional general purposed server
* Considerations for global environmental protection & sustainable use
* Liquid-cooled model downgrade to air-flow cooling model for IT using
* Provide air-flow cooling model to liquid-cooled model upgraded
  service for current limit budgets (optional, within 1 year after ordered)
10 cores, provide liquid-cooled & air-flow cooling for choice
Wolf Warrior series all cores can be running at 4.9GHz cpu frequency
Memory frequency at least 3200MHz ECC, can be changed in the future.

Our products are available in both air-cooled and liquid-cooled models for trading options. When the liquid-cooled model is no longer used, it can be easily replaced with an air-cooled architecture by purchasing a few kits. In addition, our overclocked servers It only needs 500W or 750W to operate, saving electricity and carbon emissions, allowing your business to easily meet global ESG standards.

Wolf Warrior (Air-flow cooling)

Form Factor 1U chassis with rail kit
Processor Intel Xeon W-1290P (Comet Lake) 10 cores 20MB cache base 3.7GHz CPU freq. x1
(All cores are 4.9GHz CPU frequency on Air-flow cooling operation)
Chipset Intel W580
Memory 64GB (16GBx4) DDR4-3200 ECC VLP DIMM (Max. 128GB)
Expansion
Slots
PCI-E 3.0 x16 Slot x4 (Speed for x8/x8/x1/x1)
SSD 500GB NVMe M.2 PCI-E SSD x1 (Max.3),
M.2 SATA SSD board Kits (Max.6, optional)
HFT I/O Card Solarflare X2522-25G-Plus or SFN8522-Plus ultra low latency NIC x1 (option for more)
Input / Output ASPEED AST2500 Dedicated IPMI RJ45 LAN port x1
On-board with RJ45 LAN port x1 (1Gbps x1)
* Option : Additional 1Gbps RJ45 LAN port x 1
USB port x2 (Front) , USB port x1 (Rear)
VGA port x1
* Option : COM port x1
Power Supply 500W high efficiency redundant PSU platinum level
Raid Card * Option : Hardware Raid Card with SFF8643 to 4 SATA internal cable x1 can set in
OS Preinstall optimized CentOS Linux 7.x
* Option : Red Hat Enterprise Linux 7.x / 8.x, Windows Server
Warranty 3 years hardware warranty
1 year on-side service. (limited in Taiwan)


Wolf Plus Warrior (Liquid-cooled)

Form Factor 1U chassis with rail kit
Processor Intel Xeon W-1290P (Comet Lake) 10 cores 20MB cache base 3.7GHz CPU freq. x1
(All cores are 4.9GHz CPU frequency on Liquid-cooled operation)
Chipset Intel W580
Memory 64GB (16GBx4) DDR4-3200 ECC VLP DIMM (Max. 128GB)
Expansion
Slots
PCI-E 3.0 x16 Slot x4 (Speed for x8/x8/x1/x1)
SSD 500GB NVMe M.2 PCI-E SSD x1 (Max.3),
M.2 SATA SSD board Kits (Max.2, optional)
HFT I/O Card Solarflare X2522-25G-Plus or SFN8522-Plus ultra low latency NIC x1 (option for more)
Input / Output ASPEED AST2500 Dedicated IPMI RJ45 LAN port x1
On-board with RJ45 LAN port x1 (1Gbps x1)
* Option : Additional 1Gbps RJ45 LAN port x 1
USB port x2 (Front) , USB port x1 (Rear)
VGA port x1
* Option : COM port x1
Power Supply 750W high efficiency redundant PSU platinum level
Raid Card * Option : Hardware Raid Card with SFF8643 to 4 SATA internal cable x1 can set in
OS Preinstall optimized CentOS Linux 7.x
* Option : Red Hat Enterprise Linux 7.x / 8.x, Windows Server
Warranty 2 years hardware warranty
1 year on-side service. (limited in Taiwan)

  Wolf 1U CPU Overclocked HFT Server 型錄下載.....
